Lenovo ThinkPad E14 (21JRS00400) R7-7730U 16GB, 512GB, Dos, 1Yrs

Model Configurations
PERFORMANCE
Processor
AMD Ryzen™ 7 7730U (8C / 16T, 2.0 / 4.5GHz, 4MB L2 / 16MB L3)
Graphics
Integrated AMD Radeon™ Graphics
Chipset
AMD SoC Platform
Memory
8GB Soldered DDR4-3200 + 8GB SO-DIMM DDR4-3200
Memory Slots
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory

Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Slot
Two M.2 slots
• One M.2 2242 PCIe® 3.0 x4 slot
• One M.2 2280 PCIe® 3.0 x4 slot
Max Storage Support

Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 512GB
• M.2 2280 SSD up to 1TB
Optical
None
Card Reader
No card reader
Audio Chip
High Definition (HD) Audio, Synaptic® CX11880 codec
Speakers
Stereo speakers, 2W x2, Dolby Atmos®
Microphone
2x, Array
Camera
HD 720p with Privacy Shutter
Battery
47Wh
Power Adapter
65W USB-C® (3-pin)
DESIGN
Display

14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC
Touchscreen
None
Screen-to-Body Ratio
90%
Pen
Pen Not Supported
Keyboard
Backlit, English (IN)
Dimensions (WxDxH)

313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches)
Weight

Starting at 1.41 kg (3.11 lbs)
Case Color
Graphite Black
Case Material
Aluminium (Top), PC-ABS (Bottom)
SOFTWARE
Operating System
None
Bundled Software
None
CONNECTIVITY
WLAN + Bluetooth
Realtek® Wi-Fi® 6 RTL8852BE, 802.11ax 2x2 + BT5.1
WWAN
Non-WWAN
SIM Card
None
Ethernet
100/1000M (RJ-45)
NFC
None
Standard Ports

    1x USB 3.2 Gen 1
    1x USB 3.2 Gen 1 (Always On)
    1x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
    1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
    1x HDMI® 1.4b
    1x Headphone / microphone combo jack (3.5mm)
    1x Ethernet (RJ-45)

Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® E14 Gen 5 (AMD)
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm
Smart Card Reader
None
Fingerprint Reader
Touch Style, Integrated in Power Button
Other Security

    ThinkShield
    Camera privacy shutter

MANAGEABILITY
System Management
Non-DASH
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
1Y Onsite upgrade from 1Y Courier/Carry-in
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications

 ErP Lot 6/26
 RoHS compliant
 TCO Certified 9.0

Mil-Spec Test
MIL-STD-810H military test passed
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
